home /  Non-Mydriatic Automated Fundus Camera / 21547 / AFC-330

Product Line

Product Information (  Non-Mydriatic Automated Fundus Camera  | SBJ  | 21547 )

favoritefavorite printprint
Code SBJ 21547
Name Non-Mydriatic Automated Fundus Camera
Brand NIDEK
Model AFC-330
Endorsement number
Status New Arrival
Price Make a request
Comment
The integrated high-resolution CCD camera and microcomputer remove the complicated cabling, allowing the AFC-330 to communicate via LAN without the need of an external PC in the screening area The AFC-330 pairs leading-edge technology with exceptionally smooth performance. *Fundus camera and PC built into one device *Five fully automated functions *12-megapixel high quality fundus images *Navigation of stereo and panorama photograph *Low flash intensity and quiet shutter sound
Specification & Options
Features Lower Flash Intensity & Quiet Shutter Sound Angle Of View 45° (33° In Small Pupil Photography Mode) Working Distance 45.7 mm (from Objective Lens To Cornea) Minimum Pupil Diameter Ø4.0 mm (ø3.3 mm In Small Pupil Photography Mode) Dioptric Compensation For Patient’s Eyes -33 To +35 D Total -33 To -7 D With Minus Compensation Lens -12 To +15 D With No Compensation Lens +11 To +35 D With Plus Compensation Lens . Focusing Method Infrared Focus Split Alignment Adjustable Range: -12 To +15 D Light Source For Observation: Halogen Lamp 12 V 50 W For Capturing: Xenon Flash Lamp 300 ws Flash Intensity 17 Levels From F1 (F4.0 +0.8 EV) To F17 (F16 +0.8 EV) 0.5 EV Increments Internal Fixation Target LED (maximum 9 Points) Horizontal Movement Forward / Backward: 40 mm Right / Left: 85 mm Vertical Movement 32 mm Vertical Movement Of The Chin Rest 62 mm (motorized)
Configuration
Main unit only without external PC
Condition
Patient ready
