Product Information ( Autorefractor & Keratometer | SBJ | 21400 )

$Autorefractor & Keratometer | NIDEK | ARK-1S$

Code	SBJ 21400
Name	Autorefractor & Keratometer
Brand	NIDEK
Model	ARK-1S
Endorsement number
Status	New Arrival
Price	Login Make a request

Comment

ARK-1s Autorefractor & Keratometer is a multimodality device that includes autorefraction and keratometry plus glare testing. This automated instrument measures with objective accuracy and features accommodation testing and retro illumination. Super Luminescent Diode (SLD) technology makes it possible to accurately measure patients with cataracts, corneal opacities, IOLs, and post LASIK procedures. The ARK-1s also utilizes a multiple pupil zone imaging method combined with rotary prism technology and an auto alignment Eye Tracking System to ensure consistent, accurate, reliable and repeatable data.

Specification & Options

Features: Super Luminescent Diode (SLD) for sharper images compared to LED Accurate data even through many cataracts Eye Tracking system provides X-Y-Z tracking for superior alignment and focus Large pupil zone imaging method (up to 6mm diameter) Accommodation measurement Keratometry measurement with mire ring to reduce eyelid artifacts Retro illumination illustrates media opacity in both the cornea and lens Low contrast testing Visual acuity measurement with glare testing Subjective spherical refinement Near vision testing 6.5″ high-quality, full-color LCD screen High speed printer

Configuration

Objective Spherical Refractive Error -30.00 to +25.00 D (VD = 12 mm) (0.01/0.12/0.25 D increments) Cylindrical Refractive Error 0 to ±12.00 D (0.01/0.12/0.25 D increments) Cylinder Axis 0 to 180° (1°/5° increments) Minimum Measurable Pupil Diameter ø2 mm Subjective Visual Acuity Measurements <0.1 / 0.1 / 0.25 / 0.32 / 0.4 / 0.5 / 0.63 / 0.8 / 1.0 / 1.25 <20/200 / 20/200 / 20/80 / 20/60 / 20/50 / 20/40 / 20/30 / 20/25 / 20/20 / 20/16 Spherical Refractive Error -20.00 to +20.00 D (VD = 12 mm) (0.25 D increments) Cylindrical Refractive Error 0 to ±8.00 D (Max.) (0.25 D increments) Cylinder Axis 0 to 180° (1°/5° increments) Near Addition Power 0 to +9.75 D (0.25 D increments) Corneal Curvature Radius 5.00 to 13.00 mm (0.01 mm increments) Corneal Refractive Power 25.96 to 67.50 D (n = 1.3375) (0.01/0.12/0.25 D increments) Corneal Cylindrical Power 0 to ±12.00 D (0.01/0.12/0.25 D increments) Corneal Cylinder Axis 0 to 180° (1°/5° increments) Pupillary Distance Measurement 3

Condition

Patient ready
